FXR Saddle Flange

Name: FXR Saddle Flange
Brand: Fixotec
SKU: FX-FXR-SADDLE-FLANGE

Supporting flange for FXR Mounting Rails

Application

Features & benefits

Provides higher torsional and bending rigidity for FXR Mounting rails

Simple installation by inserting the mounting rail in the saddle.

Allows lateral and vertical adjustment of FXR Mounting Rail with reliable fastening.

High load bearing capacity owing to special material properties and design.

Article list

Add the sizes you need to your RFQ basket. Pricing is quoted by our sales team based on quantity and project.

SearchProfileOrientationSurface Finish

8 of 8

Article no.	Description	Profile	Orientation	Surface Finish
FX-2290	FXR Saddle Flange – Crosswise – 41\|41, 41\|62	41\|41, 41\|62	Crosswise	Galvanized
FX-2291	FXR Saddle Flange – Crosswise – 41\|41, 41\|62	41\|41, 41\|62	Crosswise	HDG
FX-2292	FXR Saddle Flange – Lengthwise – 41\|41, 41\|62	41\|41, 41\|62	Lengthwise	Galvanized
FX-2293	FXR Saddle Flange – Lengthwise – 41\|41, 41\|62	41\|41, 41\|62	Lengthwise	HDG
FX-2296	FXR Saddle Flange – Lengthwise Heavy – 41\|124	41\|124	Lengthwise	Galvanized
FX-2297	FXR Saddle Flange – Lengthwise Heavy – 41\|124	41\|124	Lengthwise	HDG
FX-2300	FXR Saddle Flange – Lengthwise Heavy – 41\|82	41\|82	Lengthwise	Galvanized
FX-2301	FXR Saddle Flange – Lengthwise Heavy – 41\|82	41\|82	Lengthwise	HDG
